Style

Concept

The Style algebra provides methods to style pictures. There are two main ways in which a picture can be styled:

  • the stroke, which specifies the outline of a picture; and
  • the fill, which specifies what goes inside a picture.

The default is a black stroke and an empty fill.

The example below shows an unstyled circle next to a circle with a stroke color, stroke width, and a fill color.

import doodle.core.*
import doodle.java2d.*
import doodle.syntax.all.*

val basicStyle =
    .circle(100)
    .beside(
        .circle(100)
        .strokeColor(Color.purple)
        .strokeWidth(5.0)
        .fillColor(Color.lavender)
    )
A circle with no style, and a circle with a purple stroke and lavender fill

The available settings for the stroke are:

  • the color, strokeColor, or gradient, strokeGradient;
  • the width, strokeWidth;
  • the Cap, strokeCap, which specifies how lines end;
  • the Join, strokeJoin, which specifies how lines are joined together; and
  • the dash, strokeDash, which specifies a pattern to be used for the stroke.

If you don't want any stroke, you can use noStroke.

The example below shows some of the variation available with stroke styling.

val strokeStyle =
    .star(5, 50, 25)
    .strokeWidth(5.0)
    .strokeColor(Color.limeGreen)
    .strokeJoin(Join.bevel)
    .strokeCap(Cap.round)
    .strokeDash(Array(9.0, 7.0))
    .beside(
        .star(5, 50, 25)
        .strokeWidth(5.0)
        .strokeColor(Color.greenYellow)
        .strokeJoin(Join.miter)
        .strokeCap(Cap.square)
        .strokeDash(Array(12.0, 9.0))
    )
    .beside(
        .star(5, 50, 25)
        .strokeWidth(5.0)
        .strokeGradient(
          Gradient.dichromaticVertical(Color.crimson, Color.midnightBlue, 50)
        )
        .strokeJoin(Join.round)
        .strokeCap(Cap.butt)
        .strokeDash(Array(15.0, 5.0))
    )
Two stars with different stroke styles

The fill can either be one of:

  • a solid color, specified with fillColor;
  • a Gradient, specified with fillGradient;
  • no fill, specified with noFill.

The example below shows examples of using gradient fills.

val fillStyle =
    .square(100)
    .fillGradient(
      Gradient.linear(
        Point(-50, 0),
        Point(50, 0),
        List((Color.red, 0.0), (Color.yellow, 1.0)),
        Gradient.CycleMethod.repeat
      )
    )
    .strokeWidth(5.0)
    .margin(0.0, 5.0, 0.0, 0.0)
    .beside(
        .circle(100)
        .fillGradient(
          Gradient.dichromaticRadial(Color.limeGreen, Color.darkBlue, 50)
        )
        .strokeWidth(5.0)
    )
A square with a linear gradient fill, and a circle with a radial gradient fill

Implementation

The Style algebra supports all the features described above as does Image.
